Input Parameters
Input Phase Connection: 1 Phase
Input Voltage Correction Range: Min. 180 V AC – Max. 250 V AC (for Single Phase)
Board Supply Operating Voltage: 14 V AC
Continuous Full Load Operation Time: Continuous 24/7
Operating Frequency: 50/60 Hz
Output Parameters
Output Voltage: 110 V AC
Output Current: 100 A
Voltage Regulation: ±1%
Ripple Factor: <3%
Efficiency: 90%
Short Circuit Protection: <1.25 ms
General Parameters
Cooling System: Natural Convection
Transformer Type: GFTD silicon steel sheet 2A/mm2 current density, insulation class B
Display: LED Display
Display Information: Voltmeter – Ammeter
Environmental Conditions
Operating Temperature: -10°C / +50°C
Relative Humidity: <90% DIN
Operating Altitude: <3000 meters
Acoustic Level: <50 dB
Application Areas
Backup power devices • Security devices • Emergency lighting systems • Pipeline systems • Cathodic protection • Transformer centers • Computer power supplies • Generators • Production lines • DC power supplies • Inverter supply • Electrolytic coating • Battery charging • DC motor control • Forklifts • Cleaning vehicles
