INPUT PARAMETERS
Number of Input Phases: 3 Phase
Input Voltage Regulation Range: Min 110 V AC – Max 300 V AC (Per Phase)
Control Board Operating Voltage: 75 V AC (Per Phase)
Continuous Operation at Full Load: Continuous 24/7
Operating Frequency: 50/60 Hz
OUTPUT PARAMETERS
Regulated Output Voltage: 200 V AC…220 V AC…240 V AC (Adjustable from Menu)
Regulation Speed: Frequency 50 = 20 ms – Frequency 60 = 50 ms
Output Tolerance: 1%…9% (Adjustable from Menu)
Output Delay Setting: 1 sec…10 sec (Adjustable from Menu)
Output Upper Limit Cut-Off: 242 V AC…Menu Adjustable (Protected Models)
Output Lower Limit Cut-Off: 75 V AC…Menu Adjustable (Protected Models)
Overload Capacity: 10 Seconds at 200% Load
Efficiency: 98% at Full Load
GENERAL PARAMETERS
Mechanical By-Pass: With Pako Switch
Automatic By-Pass: Optional
Cooling System: Smart Fan
Harmonic Distortion: None
Input Voltage – Output Voltage Measurement: TRUE RMS (Calibration via Menu)
Display: 2×3 Digit Red LED Screen
ENVIRONMENTAL CONDITIONS
Operating Temperature: -10°C / +50°C
Relative Humidity: <90% DIN
Operating Altitude: <3000 meters
Acoustic Level: <50 dB
APPLICATION AREAS
CNC Benches – Uninterruptible Power Supplies – Medical Devices – Telecommunication Devices – Automation Equipment – Woodworking Machines – Injection Machines – Printing Machines – Radio Transmitters – Television Transmitters – Textile Machines – Design Machines – Marine Equipment – Photo Printing Machines – Sensors – Card Access Systems – Laboratory Devices – Dental Equipment – Laser Devices – Telephone Exchanges – Burglar Alarm Systems – Jewelry Equipment – Technical Devices – Air Conditioners – Motorized Shutters – Computer Systems – Lighting Units – Boilers – Warehouse Systems – Crane Systems – Automotive Devices – Motorized Machines – Market Equipment – Stacking Machines – Cooling Systems – Fire Safety Systems – Personnel Attendance Control Systems – Electrical Household Appliances
